Product Details
Model |
Power |
Stage |
Max Air flow |
Max Pressure |
Max Vacuum |
Weight |
AT-70 |
5.5KW |
1 Stage |
1200 m3/h |
241 mbar |
224 mbar |
93 kgs |
AT-85 |
7.5KW |
1 Stage |
1444 m3/h |
259 mbar |
224 mbar |
105 kgs |
AT-100 |
11KW |
1 Stage |
1700 m3/h |
241 mbar |
220 mbar |
130 kgs |
AT-100 |
15KW |
1 Stage |
1700 m3/h |
250 mbar |
230 mbar |
138 kgs |
AT-150 |
15KW |
1 Stage |
2124 m3/h |
290 mbar |
270 mbar |
145 kgs |
AT-150 |
18.5KW |
1 Stage |
2124 m3/h |
290 mbar |
270 mbar |
155 kgs |
AT-200 |
22KW |
2 Stage |
3400 m3/h |
241 mbar |
224 mbar |
198 kgs |
AT-300 |
22KW |
2 Stage |
4248 m3/h |
290 mbar |
270 mbar |
200 kgs |
AT-300 |
30KW |
2 Stage |
4248 m3/h |
290 mbar |
270 mbar |
223 kgs |
Features
- Compact design
- IEC Approved Motors
- Energy efficient
- Quiet operation
- Longer life
- Oil-free operation
- Air cooled units up to 49 deg.C inlet air temperature
- Water cooled units upto 162 deg.C inlet air temperature
- Automatic belt tensioning (1 minute belt change – no tools required)
- Low maintenance for continuous duty
Application:
Popular in canning, bottling, and food packaging ,air knives drying system ,applications
Manvac High Speed Centrifugal Blower Performance characteristics:
● Using the European IE2/IE3 standard (ABB or SIEMENS) high efficiency motor
● Oil free operation, clean air output, without any oil pollution
● Special transmission structure (impeller speed up to 13000~28400r/min)
● The surface of the Teflon coating, suitable for operation of acidic and corrosive environment
● Using Sweden SKF and Japan NSK genuine genuine high speed precision bearing,
to ensure high speed and stable operation
● Special fluid design, energy efficiency ratio of more than 70%
(2 times higher than ordinary high-pressure blower)
● Super large air volume and super power saving capacity
(2~3 times production efficiency and power saving over 60%)
