Product Details



Type
Phase		  Power   (KW) Voltage(V) Current(A) Vacuum/Presure    (max)(KPa)      Air Flow(max) (m3/min) In/Out(mm)
Noise Level    (dB)		 Weight    (Kg)
HTB75-032 3~ 0.4 220/380 1.9/1.2 2.1/2.6 6/7 75 53/65 17
HTB75-053 3~ 0.4 220/380 1.9/1.2 2.9/3.8 6.5/7.5 75 55/68 19
HTB75-104 3~ 0.75 220/380 3/2.0 3.7/5 6.5/8 75 56/70 24
HTB75-105 3~ 0.75 220/380 3/2.0 4.2/6 6.8/8.5 75 56/70 28
HTB100-102 3~ 0.75 220/380 3/2.0 3.4/4.5 11/13 100 60/74 24
HTB100-203 3~ 1.5 220/380 5.5/3.5 5/7 11/14 100 61/76 36
HTB100-304 3~ 2.2 220/380 8/5 6.5/9 12.5/16 100 63/78 42
HTB100-505 3~ 3.7 220/380 13/7.5 7.9/11 12.8/16.5 100 64/80 56
HTB125-503 3~ 3.7 220/380 13/7.5 5.8/7.9 19/23 125 70/85 57
HTB125-704 3~ 5.5 220/380 19/11.5 7.5/10.5 20/24 125 70/88 81
HTB125-1005 3~ 7.5 220/380 26/15.5 9/13 20/24 125 72/90 98
