Model | A (mm) | B(mm) | C(mm) | E(mm) | F(mm) | H(mm) | K(mm) | Φd(mm) | Tubediamter(mm) |
ST-E15H | 560 | 490 | 245 | 590 | 415 | 200 | 640 | 95 | Φ100 |
ST-E25H | 560 | 490 | 245 | 590 | 415 | 20 | 640 | 95 | Φ100 |
ST-E35H | 770 | 660 | 340 | 800 | 595 | 280 | 860 | 145 | Φ150 |
ST-E50H | 770 | 660 | 340 | 800 | 595 | 280 | 860 | 145 | Φ150 |
ST-E80H | 980 | 850 | 505 | 1010 | 785 | 330 | 1070 | 195 | Φ200 |
ST-E100H | 980 | 850 | 505 | 1010 | 785 | 330 | 1070 | 195 | Φ200 |
ST-E120H | 980 | 850 | 505 | 1010 | 785 | 330 | 1070 | 195 | Φ200 |
Model | Air Voltage | Noise | Static Pressure | Heat recovery rate | Heat recovery rate | Rted Power | Power | Protection grade | Tube diameter | Usable area |
NO | V | dB | Pa | W | V/HZ | (mm) | (m2) | |||
ST-E15H | 150/130 | 32/20/25 | 100 | 64/64 | 80/80 | 90/80 | 220V/50HZ | IP44 | Φ100 | 7-12 |
ST-E25H | 250/230 | 36/35/28 | 120 | 60/60 | 77/76 | 122/117 | 220V/50HZ | IP44 | Φ100 | 12-18 |
ST-E35H | 350/330 | 37/36/30 | 150 | 61/61 | 79/79 | 229/217 | 220V/50HZ | IP44 | Φ150 | 15-22 |
ST-E50H | 500/400 | 37/36/31 | 120 | 70/70 | 70/70 | 315/301 | 220V/50HZ | IP44 | Φ150 | 18-28 |
ST-E80H | 800/720 | 41/37/33 | 150 | 69/69 | 69/69 | 350/245 | 220V/50HZ | IP44 | Φ200 | 28-35 |
ST-E100H | 1000/780 | 41/37/33 | 115 | 69/69 | 69/69 | 450/375 | 220V/50HZ | IP44 | Φ250 | 30-45 |
ST-E120H | 1200/850 | 42/38/33 | 115 | 65/68 | 65/68 | 490/450 | 220V/50HZ | IP44 | Φ250 | 40-55 |
