Product Details

high efficiency three component flow impeller


The combination of threedimensional flow design theory
and CFD fluid simulation technology is used to ensure the
high efficiency of the product.

The high strength aviation aluminum alloy 7075 T651 is
adopted which can be used in high temperature and high
pressure working conditions.

It is made by high precision five axis machining,
and the efficiency is higher.


The impeller is directly connected to the motor shaft witho
ut transmission loss.

high speed permanent magnet synchronous motor

The electromagnetic field optimization design is adopted
to maintain th high efficiency in the whole speed range,
the efficiency can reach up to 97%, which is obviously
better than the traditional motor.

The design is improved according to the actual load demand.

The maximum rotational speed can reach 100,000 rpm.

Utilizingpremium-gradeaviation-gradematerials,high-end
permanentmagnets,andhigh-performancesiliconsteelsheets.
Dynamic pressure air bearing

Using high speed rotation to suspend itself;

The latest-generation Inconel corrugated foil bearings

enhance both support rigidity and load-bearing capacity.

The failure of bearing under high DN value and high working temperature is

solved by the optimization design of structural parameters and material selection.

On/off test:>50,000 tests.
Intelligent control system

Advanced controlsystems that can meet diverse on-site process requirements;

The special program of centrifuge can monitorthe signal oftemperature,pressure,
flow accurately,so as to ensure the safety,stability and reliability of thesystem.



The system supports smart cloud control enabling effortlessintelligent and remote control
while also streamliningequipment operation and maintenance.

High speed specialfrequency converter

High-speeddedicatedfrequencyconverterwith amaximum operatingfrequencyof100OHz.

The advanced space vector pulse width modulation technologycan fully realize the
drive requirements of high-speedcentrifugal blower.

Perfectmotor overload protection function;

The high starting torque,high speed stabilityand wide speed range.
Precision filtration system

The pressure sensor of filterrealizes the function of filtercotton replacementreminder;


With a filtration precision of 5μm and an initial pressure dropbelow 100Pa,the system

maintains efficient particle captureand low pressure loss,ensuring continuousenergyefficiency.

Long service life,extended maintenance interval.
